You are here: Home / Products / Physical Instruments / others / Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G
Share to:

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

  • Homogenizer
  • 0.04 L
  • other
  • 0.04 L
  • 1.5mlX24/2mlX24
  • 1 KG
  • New
  • cell breaking apparatus
  • plant cells, gram negative bacteria, etc
  • Other
  • China
  • Nade
  • AC220V±10% ,50~60Hz
  • 280*330*300
  • IFA
  • 0.06 kW
  • 1 Year
  • Competitive Price
  • laboratory
  • Online support
  • None
  • None
  • Ordinary Product
  • Not Available
  • Not Available
  • 1 Year
  • Other
  • Engineers available to service machinery overseas
  • P.I.D Microcomputer chip
  • LCD screen
  • Brushless motor 24VDC
  • Key
  • 2000~4500min
  • 0.5~30min
  • 0.5~6
  • 60
  • AC220 ± 10% 50~60Hz

Product Description

Product Description
Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

This product is a multifunctional and fast cell breaking apparatus.

The instrument is specifically designed for users of a practical in animal and plant cells, gram negative bacteria, gram negative bacteria, gram positive bacteria,cells and fungal spores and other rapid lysis of cells broken instrument, By the microprocessor control, the high-speed rotation of the tube impact, using high density alloy steel ball of tissue cells collide with each other, cutting and grinding, resulting in the peripheral structure of the sample cell damage; Thus releasing nucleic acids, proteins, metabolites, subcellular structure of intracellular active substances, so as to lay a foundation for the extraction and separation of the active substance from subsequent intracellular.
In addition, this product can make the homogenate liquid by crushing and homogenate processing for be the plant tissue, small insects and nuts shell samples.

Feature

HX series of cell broken device features:
1,High throughput of sample processing, single processing time no more than 3 minutes.
2,Non - contact sample handling, no cross contamination, no foam generated by the collision.
3,Used the brushless motor, low heat, long life, no carbon pollution, free maintenance.
4,There are two refrigeration ways of compressor and liquid nitrogen, avoiding the degradation of special tissues cells due to high temperature.(The compressor refrigeration needs to be reduced from 4 to 25 for 8min)
5,Preset multiple modes, easy to operate. Continuous operation and intermittent operation can be switched optionally.
6,Open cover protection, emergency brake.
7,A variety of optional grinding ball(Or zirconia ball),Different type of sample.

Specification

Model

HX-21G

Control mode

P.I.D Microcomputer chip

Display mode

LCD screen

Drive mode

Brushless motor 24VDC

Input mode

Key

Beat frequency (/min)

2000~4500

Environment of use (°C)

5~40

Refrigeration mode

Dry ice, liquid nitrogen

Amount of treatment

1.5mlX24/2mlX24

Timing (min)

0.5~30

Clearance (min)

0.5~6

Dimensions(mm)

280×330×300

Power (W)

60

Power Supply

AC220 ± 10% 50~60Hz

Certifications

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

Packaging & Shipping

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

Company Information

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

Our Services

Nade Rapid cell crusher/cell grinder/cell disrupter for dispersing ,homogenizing ,tissue breaking HX-21G

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
