L1201 Vertical flushing eye wash

Material: 304 stainless steel
Function: wash face/eye
Appearance treatment: polishing/brushing
Wash face/eye wash flow: ≥ 11.4 L/min
Availability:
  • L1201
  • NADE or customized
  • 1
  • 1 year
  • China

Product Description

The product is used in chemical plants, pharmaceutical factories, laboratories, shipyards, etc

洗眼器00_04

Specification

Model

L1201

Product name

vertical eyewash

Material

304 stainless steel

Function

wash face/eye

Appearance treatment

polishing/brushing

On-off ball valve

two-piece ball valve

Pipe diameter

38mm

Product body

304 stainless steel one-piece precision casting, thickness 3mm

Test pressure

1.6Mpa

Working pressure

0.2 ~ 0.6Mpa

Operating environment temperature

0℃~40℃

Wash face/eye wash flow

≥ 11.4 L/min

Receiving basin

304 stainless steel crimping basin, diameter 300mm

Eyewash nozzle

with filter, dust cover, flow limiter and pressure control device to meet different water pressures

Inlet/outlet size

Inlet DN15 / Outlet DN25

Executive standard

National standard GB/T38144.1/2-2019 American standard ANSI.Z358.1/2-2014

Advantages compared to similar products

all 304 stainless steel, beautiful appearance, simple installation, stable quality.
