Nade Lab Dissolved oxygen Analyzer JPBJ-608

Inquire

  • Zhejiang, China

  • Nade

  • (0.0~199.9)%

  • Dissolved oxygen Analyzer

  • LCD

  • RS-232

  • (0.00~19.99)mg/L

  • ≤0.2mg/L.

  • ≤0.1mg/L.

  • ≤20s (90% response at 20.0°C).

  • 220V 50HZ

  • Lab

Product Description

Nade Water measuring instrument Dissolved oxygen Analyzer JPBJ-608
Product Description

DO Analyzer Characteristics:

1. With the function of double displays of dissolved oxygen concentration value and temperature, dissolved oxygen saturation value and temperature
2. Measuring D.O. concentration, saturation, electrode current and temperature; With the functions of automatic temperature compensation and calibration of zero oxygen, full scale, atmosphere pressure and salinity.
3. The meter has the function of protection from electricity cutting off. With Measuring results can be stored, deleted, viewed and printed. At most 250 sets of data can be stored.
4. With wide screen LCD. It is easy to operate with the prompt facility. With PC panel of new material, thus the meter has good reliability.
5. With low power consumption design, with the functions of lack of voltage display, switching off automatically.
6. With RS-232 interface which is connected and with Model TP-16 printer to print measuring results or connected with computer to communicate.
7. Grade of the case protection is IP65, resistant to water and dirt, suitable for field operation
8. The electrode system is composed of polarographic oxygen electrode and temperature electrode.

Specifications
1. Measuring range:
Dissolved oxygen concentration: (0.00~19.99)mg/L
Dissolved oxygen saturation: (0.0~199.9)%;
Temperature: (0~40.0)°C.
2. Automatic temperature compensation range: (0.0~40.0) °C.
3. Accuracy of the meter:
D.O. concentration:±0.3mg/L±1bit(under basic temperature);
±0.5mg/L (differ: ±15°C from the basic temperature)
D.O. saturation : ±5.0% (under basic temperature);
±10.0% differ: ±15°C from the basic temperature
Temperature: ±0.5°C±1bit.
4. Repeatability of the meter: ≤0.2mg/L.
5. Stability of the meter: not over ±0.2mg/L within one hour.
6. Remaining current: ≤0.1mg/L.
7. Response time ≤20s (90% response at 20.0°C).
8. Salinity calibrating range: (0.0~40.0)g/L.
9. IP65 protection grading
Packaging & Shipping

Our Packaging Details:

Nade Lab Dissolved oxygen Analyzer JPBJ-608

Our Shipping

Nade Lab Dissolved oxygen Analyzer JPBJ-608

Company Information

Nade Lab Dissolved oxygen Analyzer JPBJ-608

Nade Lab Dissolved oxygen Analyzer JPBJ-608

Our Services

Nade Lab Dissolved oxygen Analyzer JPBJ-608

FAQ

Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.


Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.


Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.


Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
