1year
Conductivity Meter
Zhejiang, China
NADE
EC700
0.1/1μS/cm_0.01/0.1 mS/cm
±1.0% FS ±1 digit
0 to 50°C (32 to 212°F) Auto or Manual
0.1 / 1 / 10 cm-1
25°C (77°F)
0.00 to 9.99%/°C, default: 2.00%/°C
1 to 4 points auto calibration
Input: 120V AC 60Hz; Output: DC9V/300mA, 2.7VA
Product Description
The Instruments EC700 Benchtop Conductivity Meter/Tester Kit provides quick and stable conductivity/TDS measurements for basic laboratory testing and educational purposes at outstanding cost-effectiveness.
Reliable Measurement:
With unique BPB (Brush-Resistant Platinum Black) conductivity electrode/sensor and the advanced digital processing technology, the measuring of conductivity and temperature is quick, accurate and stable in a wide measuring range (accuracy: ±1% F.S, Range: 0 to 200.00 mS/cm). IP54 Splash-proof and Dust-proof structure design, ideal for use in harsh environment.
Intelligent Functions:
Quick& Easy Auto Calibration: automatically recognizes 8 types of conductivity standard solutions. 0 to 100°C(32 to 212°F)auto temperature compensation. 50 groups of data storage. Max/Min measuring mode available, alternately displaying the maximum and minimum readings.
Comes with an easy-to-install electrode holder and 3 bottles of premixed conductivity calibration solutions (84 μS/cm, 1413 μS/cm, 12.88 mS/cm). The product is CE certified and comes with a Two-Year warranty for the meter; 6 months for the electrode.
1. Equipped with 2301T-F Combination Conductivity Electrode, Auto. Temp. Compensation, measuring conductivity and temperature simultaneously
2. AdvancedAuto Calibration Mode with Calibration Guide and Self-Diagnosis
3. Advanceddigital processing technology helps generate quick and stable readings
4. IP54 Spill-proof and Dust-proof, durable and reliable
5. Comes with easy-to-install electrode holder and pre-mixed calibration solutions
6. 50 Groups of Data Storage
| model | EC700 | |
| Conductivity | Measuring Range | Conductivity: 0~200.0 mS/cm_include (0 to 199.9) μS/cm; (200 to 1999) μS/cm; |
| Resolution | 0.1/1μS/cm_0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS ±1 digit | |
| Temperature Compensation | 0 to 50°C (32 to 212°F) Auto or Manual | |
| Electrode Constant | 0.1 / 1 / 10 cm-1 | |
| Base Temperature | 25°C (77°F) | |
| Temperature Coefficient | 0.00 to 9.99%/°C, default: 2.00%/°C | |
| Calibration | 1 to 4 points auto calibration | |
| Temperature | Measuring Range | 0 to 80°C (32 to 212°F) |
| Resolution | 0.1°C; 0.1/1?F | |
| Accuracy | ±0.5°C±1 digit | |
| Others | Data Storage | 50 groups |
| Storage Content | Numbering, measurements, unit, temperature, and status of temperature compensation | |
| Power Supply | Input: 120V AC 60Hz; Output: DC9V/300mA, 2.7VA | |
| IP Rating | IP54 splash-proof and dust-proof | |
| Dimensions and Weight | (9.5*9.3*4) inches / 2.2 pounds; With case: (12*10*5) inches / 3 pounds | |
Other models:
EC910 PH9500
