EC310F Portable Conductivity Meter

Conductivity range: 0.000 μ S/cm to 500 mS/cm
Resistivity range: 5.00 Ω ·cm~20.00 M Ω ·cm
TDS range: 0.00mg/L~300g/L
Salinity Range: (0.00~8.00)%
Availability:
  • EC310F
  • Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output
  • 1
  • 1 year
  • China

Product Description

EC310F

● LCD display screen, 3.5 inches.

● Multi-reading feature allows auto-read, timed-read and continuous-read.

● Automatic/Manual temperature compensation ensures accurate results.

● Auto-hold feature senses and locks the measurement endpoint.

● Data capacity of up to 500 sets for each parameter (GLP-compliant).

● Support for USB communication.

● Auto-power off feature effectively extends the battery service life.

● Reset feature automatically resumes all settings back to factory default options.

● IP65 waterproof. The portable meter is suitable for fields measurements and out door measurements.

● 1-3 points calibration with Standard Recognition.

● Settable parameters, including cell constant, temperature compensation coefficient, and TDS factor.

● Temperature compensation type (none, linear, pure water).


Specification

Model

EC310F

Parameters

EC/Temp.(Resistivity/TDS/Sal.)

     Conductivity

Range

0.000 μ S/cm to 500 mS/cm



Resolution

0.001 μ S/cm minimum,

various with range selection



Accuracy

± 1.0% FS



Reference Temperature

20, 25 ºC



Calibration Points

Up to 3



Standard Recognition

84 μ S/cm, 1413 μ S/cm, 12.88mS/cm

Resistivity

Range

5.00 Ω ·cm~20.00 M Ω ·cm



Resolution

0.01 Ω ·cm minimum



Accuracy

± 1.0% FS

TDS

Range

0.00mg/L~300g/L



Resolution

0.01mg/L minimum, various with range selection



Accuracy

± 1.0%FS

Salinity

Range

(0.00~8.00)%



Resolution

0.01%



Accuracy

± 0.2%

    Temperature

Range

-5 to 110 ºC, 23 to 230 ºF



Unit

ºC, ºF



Resolution

0.1



Relative Accuracy

± 0.2

Measurement

Reading Mode

Auto Read (Fast, Medium, Slow), Timed, Continuous



Reading Prompts

Reading, Stable, Locked



Temp. Compensation

ATC, MTC

Data management

Data Storage

500 results each



GLP Features

Yes

Inputs

Conductivity with Temp. Probe

5-pin aviation connector

Outputs

USB

PC, printer

   Display options

Backlight

Yes



Auto Shutdown

300, 600, 1200, 1800, 3600 sec., off



IP Rating

IP65



Date and Time

Yes

General

Power

Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output



Dimensions

90 × 255 × 40 mm



Weight

400g (0.88 lb)


Configuration

DJS-1VTC EC Electrode

1413μS/cm Conductivity Standards Solution 1 Bottle (50ml/bottle)

Electrode Hanger Protective Cover

Wrist Strap Assembly

Portable Protective Case


DJS-1VTC EC ElectrodeConductivity Standards Solution
