NADE 20L Laboratory LED Digital Overhead Stirrer

Share to:

NADE 20L Laboratory LED Digital Overhead Stirrer



Inquire

Mixer Type:
Paddle
Barrel Volume (L):
20
Material Processed:
Chemicals, Medicine
Max. Loading Volume (L):
20 L
Max. Loading Capacity:
20L(H2O)
Weight (KG):
2.8 KG
Condition:
New
Product Type:
wide range, such as cosmetics, pharmaceutical, solution
Application:
Liquid
Additional Capabilities:
light alarm
Place of Origin:
Zhejiang, China
Brand Name:
NADE
Voltage:
100V~220V
Dimension(L*W*H):
83*220*186mm
Certification:
ISO, CE
Power (kW):
0.07 kW
Warranty:
1 year
Key Selling Points:
Easy to Operate
Applicable Industries:
laboratory
After Warranty Service:
No service
Local Service Location:
None
Showroom Location:
None
Marketing Type:
Ordinary Product
Machinery Test Report:
Not Available
Video outgoing-inspection:
Not Available
Warranty of core components:
1 Year
Core Components:
Other
After-sales Service Provided:
No overseas service provided
Stirring capacity:
20L (H2O)
Motor type:
DC Brushless motor
Speed range:
50-2200 rpm
Display mode:
LED
Max Viscosity:
10000mPas
Stirring paddle material:
SS316 or PTFE

Product Description

Product Description

How to choose

Don't know which is the most suitable stirrer for your application?
→ Then pls do not hesitate to inquire us!
→ In order to get a quick recommendation, Pls inform us your application, what material to mix, requirement on capacity/speed/continuous stirring time, etc.

Introduction

Overhead Stirrers can accomplish the most demanding tasks and provide high safety and increased performance. They are widely used in chemical synthesis, pharmaceutical synthesis, physical and chemicalanalysis,petrochemical industries, etc.

Features

1.High reliability and outstanding performance
2.A wide range of speed from 50 to 2200rpm
3.Brushless DC motor for long life, maintenance free and explosion proof
4.LED display for precise monitoring of actual speed
5.Safety circuits allow for safe stop function in anti-stall or overload Conditions
6.Explosion-proof

Specification

	OS20-S	OS40-S
Max. stirring quantity(H2O)	20L	40L
Motor type	Brushless DC motor	Brushless DC motor
Motor rating input	60W	120W
Motor rating output	50W	100W
Voltage	100~220V, 50/60Hz	100~220V, 50/60Hz
Power	70W	130W
Speed range	50~2200rpm	50~2200rpm
Speed display accuracy	±3rpm	±3rpm
Speed display	LED	LED
Torque display	NO	NO
Overload protection display	LED lights	LED lights
Max. torque	40Ncm	60Ncm
Viscosity max.	10000mPas	50000mPas
Chuck range diameter	0.5~10mm	0.5~10mm
Dimension[W x H x D]	83220186cm	83220186cm
Weight	2.8kg	2.8kg
Permissible ambient temperature and humidity	5~40℃, 80%	5~40℃, 80%
Data connector	NO	NO

Optional accessories

Ordering information of full set: Motor+all necessary clamp+rod+plate+1 pc of paddle.
We provide SS316L paddle and PTFE paddle at different, Pls choose one or more paddle among OSA01~OSA08.
