NADE 10L* 4 Position Magnetic Stirrer with 340C Hotplate

  • 1 year
  • Laboratory Heating Equipments
  • other
  • NADE
  • MS-H340-S4
  • Zhejiang, China
  • RT~340℃
  • 40L (10L*4 position)
  • Stainless steel with ceramic coating, chemical resistant
  • diameter 134mm (5inch)
  • Brushless DC Motor
  • 200-1500rpm

Product Description

NADE 10L* 4 Position Magnetic Stirrer with 340C Hotplate

NADE10L* 4 Position Manetic Stirrer with 340℃ Hotplate

Seperately Control

Introductions

It is widely used in chemical synthesis,physical and chemical analysis, bio-pharmaceuticals etc.

Features:

• Independent heating and stirring control

• LCD display shows actual temperatures and speed

• PID controller ensures a precise and steady heating process, Max.temperature up to 340

• Brushless DC motor enables more powerful speed control

• External temperature sensor(PT1000) with accuracy at 0.2

• Overheating protection temperature at 420

• Stainless steel work plate with ceramic coating provides good chemical-resistant performance

• A wide variety of accessories are available

Specification:

Specifications

MS-H340-S4

Work plate dimension

Φ134mm (5inch)

Plate material

Stainless steel with ceramic coating

Motor type

Brushless DC motor

Motor rating input[W]

1.8W×4

Power[W]

515W×4

Heating Power[W]

500×4

Voltage

100-120V,60Hz; 200-240V,50 Hz

Stirring positions

4

Max. stirring quantity

of single position (H2O)

10L

Max. magnetic bar[mm]

40

Speed range[rpm]

200-1500

Speed display

LCD

Temperature display

LCD

Control accuracy of sensor[rpm]

±20

Temperature range[°C]

25-340℃

Over temperature protection[°C]

420

Temperature display accuracy[°C]

±0.1

External temp. sensor

PT1000 (Accuracy±0.2℃)

IP Protection class

IP21

Dimensions[WxDxH][mm]

698×270×128

Weight[kg]

9.5kg

Permissible ambient temperature[°C]

5~40

Permissible relative humidity

80%
