MS7-H280-G
NADE
100-120/200-240, 50/60Hz
1
OEM
1 year
China
Product Description
Features
Ø Microcrystalline Glass Surface, High flatness, scratch-resistant, corrosion-resistant, and easy to clean.
Ø Full Coverage Infrared Heating Element, even heat distribution, fast response, quick heating speed, high efficiency, and minimal overshoot.
Ø Overheat Protection: ensures safe heating throughout the process.
Ø “Hot” warning flashes if plate temperature is above 50°C even when hotplate isturned off to prevent burns.
Ø Liquid Drainage Groove: Located above the control panel to prevent corrosion of the equipment, even if liquid splashes.
Ø LCD Display: Quickly set heating temperature, stirring speed, and other parameters.
Ø Brushless DC Motor: Spark-free, strong stirring power.
Ø Maximum Adjustable Speed: 1500 rpm;
Ø Maximum adjustable temperature: 280°C.
Ø External PT1000 Temperature Sensor: Improves temperature control accuracy to ±0.2°C.
Ø RS232 Interface: Can connect to a computer for remote control and data saving
Specification
Model | MS7-H280-G |
Work plate Dimension (W×D) | 180mm×180mm |
Work plate material | Microcrystalline Glass |
Motor type | Brushless DC motor |
Stirring positions | 1 |
Max. stirring quantity, [H₂O] | 20L |
Max. magnetic bar[length] | 80mm |
Speed range & accuracy | 100-1500rpm, ±10rpm |
Speed display | LCD |
Temperature display | LCD |
Heating temperature range | Room Temp.-280℃, increment 1℃ |
Temperature control accuracy | ±1℃ (<100℃), ±1% (>100℃) |
Overheating protection | 340℃ |
Temperature display accuracy | 0.1℃ |
External temperature sensor | PT1000 (accuracy ±0.2℃) |
"Hot" warning | 50℃ |
Data connector | RS232 |
Protection class | IP21 |
Motor rating output | 10W |
Power | 1050W |
Heating output | 1000W |
Voltage/Frequency | 100-120/200-240, 50/60Hz |
Dimension (W×D×H) | 215×360×112mm |
Weight | 3.7 kg |
Permissible ambient temperature and humidity | 5-40℃, 80%RH |
