Hotplate Magnetic Stirrer MS-H-S10

Motor type:Brushless DC motor
Speed range [rpm]:0-1100rpm
Work plate dimension[W x D]:180x450mm
Protection class:IP20
Availability:
Inquire

  • MS-H-S10

  • NADE

  • MS-H-S10

  • 100~120V /200~240V,50/60HZ

  • 1

  • 1 year

  • China

Product Description

NADE 10 Channel Analog Laboratory Hotplate Magnetic Stirrer MS-H-S10

10-Channel Classic Magnetic Stirrer, Aluminium

Advantages

1. Maintenance-free brushless DC motor °C
2. Maximum speed 1100rpm
3. Maximum temperature of work plate up to120℃
4. Stainless steel work plate, Covered with silicone cushion, provide excellent of heating uniformity and skid resistance

Specification

ModelMS-H-S10
Work plate dimension[W x D]180x450mm
Work Plate materialStainless steel covered with silicone cushion
Motor typeBrushless DC motor
Stirring positions10
Max. stirring quantity0.4Lx10
Max. magnetic bar [length]40mm
Speed range0-1100rpm
Speed displayscale
Temperature displayscale
Heating temperature rangeRoom temp.-120℃
Over temperature protection140℃
IP Protection classIP21
Motor rating output4W
Power490W
Heating Powe470W
Voltage,Frequency100-120/200-240V，50/60Hz
Dimensions[WxDxH]182×622×65mm
Weight3.2kg
Permissible ambient temperature and humidity5-40℃, 80%RH
