NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera

  • China

  • NADE

  • LED

  • Yes, very light and small, only 550g

  • Yes, large screen

  • Yes

  • Yes

  • About 0.5 seconds

  • paper, food, plastic cement, printing, paint, weaving and dyeing

  • with camera

Product Description

Introductions:

There are several models in CS Series portable colorimeter, pls choose a most suitable model or inquire us for help.

Application:

Colorimeter is widely used in different industries such as food, plastic cement, printing, paper, paint, weaving and dyeing.

It measures the sample color data L*a*b*, L*c*h*, color difference E and Lab according to CIE color space.

NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera

Product Characteristic:

NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera

  • CS-10 is the basic model with wide functions and is very economical.
  • CS-200 is an upgraded version of CS-10, improves the measurement accuracy, and increases the yellow and whiteness measurement function. It is in high performance- price ratio.
  • CS-210 includes a camera for measurement spot view. previous color measurement instrument can only align with the test spot approximately, and can easily incur errors.

NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera

  • CS-220 includes specular component excluded (SCE)measurement mode, which is especially suitable for measuring and managing the color data of powder ,high light colloid and so on.

NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera NADE CS-210 High Accuracy Digital Portable Colorimeter with Camera

  • CS-260 Color card reading colorimeter can read the color samples and display the most similar color card number. It’s widely used in printing, printing and dyeing, clothing, decoration, design, construction, Home Furnishing, food industry etc.
Specification

Type

CS-10

CS-200

CS-210

CS-220

CS-260

Illumination system

8/d(8°/diffused illumination)

SCI(specular component included)

SCE

SCI

Display modes

Colorimetric values: L*a*b,L*C*h,E*ab,XYZ,Yxy, relative RGB values;

Color difference values: (L*a*b),(L*C*h);

--

Whiteness values:hunter whiteness,ganz whiteness Yellowness value: Hunter WI, Gantz WI,YI

Measuring caliber

8mm and 4mm

Measuring conditions

CIE 10° standard observer; CIE D65 light source

Measuring range

L*:1-100

Repeatability

Standard deviation within E*ab*,0.08(condition: measure the white calibration board 30 times for average)

Storage

100 sets of standard samples; up to 100 under each standard sample

Measuring time

About 0.5 seconds

Measuring light source

LED

Halogen lamp

LED

Languages

Chinese,English

Power

4 AA1.5V Alkaline battery or nickel-metal hydride batterys;Exclusive DC5V adapter

Port

USB2.0 printer

Weight

550g

Size

77×86×210mm

Others

Lowest Price

High Performance Price Ratio

Camera for sample view

powder, colloids measuring

Color card reading
