You are here: Home / Products / Stirrer/Homogenizer/Shaker/V Mixer / Homogenizer / HX-MiNi300 Handhold Ultrasonic Homogenizer
Share to:

HX-MiNi300 Handhold Ultrasonic Homogenizer

Power: 7-300W
Crushing volume: 0.1~300mL
Frequency: 30KHz
Standard horn: Φ6mm
Availability:
  • HX-MiNi300
  • NADE
  • 100-230V/AC 12-24V/DC
  • 1
  • 1 year
  • China

Product Description

HX-MiNi300 P2

The MiNi ultrasonic homogenizer is a sample pretreatment instrument with an integrated structure design that uses ultrasonic waves to generate cavitation effects in liquids. It is mainly applicable to dispersion of nano materials, cell wall breaking extraction and crushing, homogeneous mixing, chemical synthesis, oil-water emulsification, etc


Feature

* Wide voltage design, applicable to a wide range;
* Can be equipped with a car power cord, which is suitable for outdoor use;
* Integrated structure design, compact shape, light and exquisite;
* A variety of horn specifications are available, with a wide processing range, up to 300ml;
* Frequency tracking and amplitude compensation adopt automatic mode, with stable load and high electro-acoustic conversion rate;;
* The horn is made of titanium alloy material, which has high strength, strong corrosion resistance, high heat resistance and long service life;
* It can be hand-held or can be fixed with an optional bracket. It can be used in various ways, especially suitable for ultrasonic treatment of trace or small amount of samples.

Specification

Model

HX-MiNi300

Power

7-300W

Crushing volume

0.1300mL

single ultrasound time

Within 30 minutes (considering sample temperature)

Operation mode

continuous

Frequency

30KHz

Standard horn

Φ6mm

Optional horn

Φ1.52368

Horn material

TC4 titanium alloy

Input voltage

100-230V/AC 12-24V/DC

control method

Button (blue light)

Optional features

Bracket

Voice alarm and prompt function

Protection appears, the power cord will flash

Net weight/gross weight

0.4/0.8kg

Instrument size (L*W*H)

320*40*47mm

Package size (L*W*L)

470*330*200mm


Optional accessories

Order No

Horn Size

Capacity(ml)

20080037

Φ1.5

0.1~5

20080038

Φ2

0.1~10

20080039

Φ3

0.1~100

20080040

Φ6

0.1~200

20080047

Φ8

0.1~300
