SNB-1
NADE
AC 220v±10%,50Hz Optional: AC 110V±10%
1
1
China
Product Description
Usage:
It is used to measure viscosity resistance and absolute viscosity of fluids, including lipid, oil, food. Many applications such as cosmetic, grease, painting, pharmacy and adhesives.
Features:
1. New digital product based on the single chip micro-processor technologies
2. Used for determining the liquid viscose capacity and the absolute viscosity.
3. Comparing with other similar products, this instrument has the following features:
High measuring accuracy;
Stable in measured display;
Easy operation and read-out;
Excellent in Anti-interference.
Model | NDJ-8S | NDJ-5S | SNB-1 |
Display mode | digital | ||
Rotors speed(r/min) | 0.3/0.6/1.5/3/6/12/30/60 | 6/12/30/60 | 6/12/30/60 |
Speed governing | Eight level | Intelligence | Intelligence |
Rotor | 1,2,3,4 | ||
Measure Range(mPa.s) | 10~2×106 | 10~105 | 10~105 |
Measure error( Newtonian liquid ) | ±5% | ±2% | |
Dimension(mm) | 275×230×475 | ||
Voltage(V) | 110-240 | ||
No zero Rotor: specially used for small sample or low viscosity sample.
Our viscometer can work together with our Thermostatic Bath NDC series
We have other viscometers for your reference, rotary viscosimeter, Brookfield Viscometer, Engler viscosimeter,Storm Krebs viscometer and so on. For Newtonian liquid and non-Newtonian liquid, high viscosity and low viscosity whether in large capacity or small capacity.
