Zhejiang, China
Nade digital viscometer
SNB-2
1-6000000
0.1-99.9
Product Description
Introduction:
It is characterized by 16 bit micro processor core controlled circuit, gearless driven, LCD in bule color, of percentage, spindle number and the maximum value of the measurable viscosity at the current rotation speed. Its
keyboard is designed strikingly.
It is stable for rotation speed and accurate for measured result.
It is equipped with RTD temperature detective probe and RS232 output interface,the viscometer can store, compare and record the data after connecting to PC (The function for automatic data collection via PC port is optional)
By adopting the Surface Mount TechnologySMT), the circuit is compact structured in areasonably arranged layout. The series
product has almost reached to the advanced
international level compared with the equivalents in other countries in terms of itsmeasurement performance and function.
| Model | SNB-1 | SNB-2 | SNB-3 |
|
| |||
| Measured Range | 1-600000 | 1-6000000 | 4-80000000 |
| (mPa.S) | |||
| Rotation Speed | 1-60 | 0.1-99.9 | 0.1-99.9 |
|
| |||
| Number of Spindle | 4types(#0 spindle is for option) | ||
|
| |||
| Measurement | ±1.0%(FS) | ||
|
| |||
| Repeatability | ±0.5% | ||
|
| |||
| Power | The adapter is the standard supply(input 220V±10% 50±1Hz) | ||
|
| |||
