NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

  • laboratory
  • Online support
  • None
  • None
  • Not Available
  • Provided
  • Ordinary Product
  • 1 Year
  • other
  • New
  • China
  • NADE
  • 1000
  • 46cm*40cm*50cm
  • 1 Year
  • Online support
  • Easy to Operate
  • AC(220±10%)V, 50Hz
  • 1000W,continuous adjustment
  • 100ml,scale division 1ml
  • 125mL. It can meet requirements GB/T 6536 and ASTM D86
  • (-2~300)℃ and (-2~400)℃. Division value 1℃
  • SiC,diameter for each hole is dia.32mm,dia.38mm and dia.50mm
  • Room temp.~+35℃
  • ≤85%
  • 1100W
  • 460mm*400mm*500mm

Product Description

Product Description

This instrument is designed and made as per standards GB/T6536 Test Method for Distillation Characteristics of Petroleum Products and ASTM D86 Standard Test Method for Distillation of Petroleum Products at Atmospheric Pressure. It is suitable to determine the distillation characteristics of gasoline, aviation gasoline, jet fuels, and solvent having special boiling point, naphtha, diesel oil, distillate fuels and similar petroleum products.

Feature

1. This instrument is desktop structure. The design is reasonable. It is easy to use.

2. It adopts a special heating furnace to ensure the safety. The heating power can be adjusted continuously.

3. The rising up and lowering down of distillation flask can be adjusted free by lifting device.Flexible and convenient to operate.

Specification

1. Power supply: AC(220±10%)V, 50Hz

2. Heating power: 1000W,continuous adjustment

3. Receiving cylinder: 100ml,scale division 1ml

4. Distillation flask: 125mL. It can meet requirements GB/T 6536 and ASTM D86

5. Thermometer: (-2~300)℃ and (-2~400)℃. Division value 1℃

6. Flask support board: SiC,diameter for each hole is φ32mm,φ38mm and φ50mm

7. Ambient temperature: Room temp.~+35℃

8. Relative humidity: ≤85%

9. Maximum power consumption: 1100W

10.Dimension: 460mm×400mm×500mm

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

Other models:

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

SYD-255 SYD-255K SYD-6536A SYD-6536B

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

SYD-6536B-1 SYD-6536C SYD-6536D SYD-6536K

Our Services

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

Company Information

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

NADE SYD-6536 Single Tube Distillation Apparatus for Petroleum Products 100ml 125ml

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
