NADE Digital Rotational Viscometer Price
LDV : #1, #2, #3, #4 are standard configurations (#0 is optional)
±0.5% of range
Product Description
NADE Digital Rotational Viscometer Price
1. 7 inch touch screen with rich information (easy to operate)
2. Anti-static shell and metal lifter
3. Build-in RTD temp probe
4. ARM chip processor for higher data processing speed
5. New designed durable axle
6. Powerful human-computer interactive interface
7. Gigabit Ethernet port to ensure rapid and stable data transfer.
8. External storage supports: single point, continuous and timing data, three kinds of storage
9. Correction factor of temperature and viscosity protection (password protection)
10. Variable speed support of viscosity measurement
11. Auto switch between dynamic viscosity and kinematic viscosity
12. Variety of viscosity units
13. different operation interface style
14. Detailed operation guide
15. Continuous viscosity value displayed
16. Sound alarm when beyond measurement range
17. Linear calibration by computer
Applications:
Ink; Glue; Latex; Solvent Adhesive
Polymer Solution; Oil; Paint; Solvent;
Cosmetics; Dairy Products; Drugs; Juice and etc
SNB software (for data collecting and painting)
Thermostatic water bath (for viscosity measurement)
Ultra low viscosity adapter
Small sample adapter
External circulatory glass beaker
Micro printer
NTV Series Viscosity Ranges(mPa.s):
1M=1million
| Type | NTV-S1 | NTV-S2 | NTV-S3 | NTV-AI |
| Range(mPa.s) | 1-0.6M | 1-6M | L:1-2M R:100-13M HA:200-26M HB:800-104M | 1-6M,4-80M |
| RPM | 1-60 | 0.1-100 | 0.1-100 | 0.1-200 |
| Measurement | Manual operation | Manual operation, Intelligent touch | ||
| Spindles | L:No.1,2,3,4 (No. 0 is optional) R,HA,HB:No.2,3,4,5,6,7 (No. 0,1 is optional)
| |||
| Accuracy | ±1.0%(of full range) | |||
| Repeatability | 0.5% | |||
This series is an upgraded version of DV-1+Pro
