Lab
None
None
New
Zhejiang, China
Nade
Nitrogen
200
220V
5.8kgs
Dia 360x820mm
ISO
1 Year, 1 year
Online support, Engineers available to service machinery overseas
Easy to Operate
Ordinary Product
Not Available
Not Available
1 Year
Other
220v
24
water bath
0-10L/min
Nitrogen Generator
HSC-24B
nitrogen concentration
Pressed gas Blowing Concentrator
Product Description
Nade Gas Generation Equipment Nitrogen Evaporator HSC-24B 24 samples Nitrogen Generator
The Nitrogen Evaporation adopts the blowing-trapping technology and uses inert gases such as nitrogen to handle the sample, and achieves the separating, purifying, and oxygen-free concentration. The instrument enjoys the time-saving, convenient, and accurate features. It is widely used in the pharmacy, medical test, pesticide residue detection, etc.
Feature:
1.Healer-Block Type(HGC series) and water-Bath Type (HSC series) satisfy the different user' demands.
2.The needles can be used respectively. The height of nitrogen distributor is adjustable according to the demads.
3.Digital temperature controller, Dual-digital display. PID technology, and Over-temperature.
4.The parts which may contact with the solvent are made of 316 stainless steel, aluminum or the surface is plastic spraying. Long service life and easy to clean.
5.HGC series (standard:φ15mm,φ17mm or φ21mm,special model can be ordered in advanced from manufacturer.
Specification:
| Model | samples | Blocks | Temp Accuracy | Temp control | Flow rate | Dimensions | Power | weight |
| HSC-24B | 24 | Water Bath | +/-1 °c | Digtal Display/ PID Adjustment/Over- Temp protection/ PTC Heating | 0-10L/min | Φ360x820mm | 200w | 5.8kg |
| Notice: Temperature range: Heater block: Ambient----120 °c Water Bath: Ambient ----100 °c |
Accessories:
| Product | Specification | Notice |
| block | Φ15mm,T45mm | Round bottom |
| block | Φ15mm,T45mm | Round Bottom |
| block | Φ15mm,T45mm | Round Bottom |
| block | Φ15mm,T45mm | Round Bottom with 6 holes |
| block | Φ15mm,T45mm | Round Bottom with 2 Holes |
| Tube Support | Aperture-diameter options
| Special block can be ordered in advanced |
| Needle | Length 158mm |
Water-bath Tube support Aperture-diameter options. Special Block can be ordered in advanced
More models pls click the model formore details
HGC-12A HGC-12D HGC-24A
Our Packaging Details:
Our Shipping
Hot Selling Products..........
 |  |  |
 |  |  |
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.
Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.
Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.
Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.
Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
