NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

  • Vacuum Drying Equipment

  • 2kg

  • Medicine Processing, Chemicals Processing, Food Processing

  • New

  • China

  • Nade

  • 220V 50HZ

  • 750W, 1700W

  • 40cm*55cm*70cm

  • CE Certificate

  • Easy to Operate

  • 1 Year

  • 50

  • Video technical support, Online support

  • Food & Beverage Factory, Home Use, Food Shop, Food & Beverage Shops, Laboratory

  • None

  • None

  • Ordinary Product

  • Provided

  • Not Available

  • 1 Year

  • Pump

  • 0.1㎡

  • -40℃

  • 15Pa

  • 1~2KG/Wholesale

  • 45mm

  • 220V;50HZ

  • 50KG

  • 140*278mm 3 floors

  • 40cm*55cm*70cm

Product Description

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

Product Description

The small in-situ lyophilizers are adopted with imported configuration, which is characterzied by stability and reliability and many other advantages, such as good-looking appearance, small volume, light weight and easy operation. They can be widely applied to many fields, such as foods, biological products, chemical engineering, traditional Chinese medicinal materials and health care products.

Applications:

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

Feature

1.Patented products with advanced technology.

2.The products are beautiful and fashionable and the dimension is small.

3.Operate on touch screen, one key start and automatical control freeze-drying process, easy and convenient operation.

4.Set and real-timely adjust freeze-drying technology by requirement and show the freeze-drying data and curve.

5.The imported key components are characterzied by low noise, great power, high quality and high performance.

6.Advanced system, small running current and low energy consumption.

7.Dish and inner tank are made of SUS304 stainless steel, which guarantees the safety of product.

8.Fast defrosting technique and automatic protection for overheat.

9.The transparent organic glass door is helpful in observing the freeze-drying process of materials.

Specification
  1. Model TF-HFD-1
  2. Lyophilizing Acreage 0.1m^2
  3. Cold trap Temperature -40℃
  4. Ultimate Vacuum 15Pa
  5. Material Handling Capacity 1~2kg/Wholesale
  6. Shelf Spacing 45mm
  7. Power Supply 220V;50HZ
  8. Power 750W
  9. Equipment Weight 50Kg
  10. Shelf Dim 140*278mm;3 floor
  11. External Dimensions 40cm*55cm*70cm

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

other models:

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

TF-HFD-1 TF-HFD-4

Certifications

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

Packaging & Shipping

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1 NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

Our Services

Please contact us by alibaba message or TEL: +0086-571-88064952 for any requirements or questions. There may be a time zone difference depending on your location, but we will respond to you as soon as we can.

We cherish every opportunity to serve our customer! It will be our great pleasure to do business with you and hope it will be a win-win situation for both of us.

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

Company Information

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

NADE In-Situ Minitype Lyophilizer/freeze drying equipment/freeze dryer 0.1m^2 TF-HFD-1

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
