NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Inquire

  • 1 year

  • hardness tester

  • other

  • Zhejiang, China

  • NADE

  • HRD-45

  • 170mm

  • 135mm

  • 0.5HRN(T)

Product Description

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Feature

High testing efficiency,with high accuracy hydraulic buffer,durable and reliable loading;

Direct dial readings,with scales of HRA,HRB and HRC(other optional);

Precision hydraulic buffers, loading smooth and adjustable speed;

Automatic testing process without human operation error;

Precision conforms to GB/T230.2National Standard, ISO6508-2,ASTM E18 standard.

Applications

Determine the superficial hardness of ferrous metals, alloy steel, carbide and metal after nitriding, cyanidation, carburizing, electroplating and other surface treatment .

Specification

Measuring range

70-94HR15N, 42-86HR30N , 20-77HR45N

67-93HT15T, 29-82HR30T, 10-72HR45T

Test force

147.1, 294.2, 441.3N (15, 30, 45kgf)

Max. height of test piece

170mm

Depth of throat

135mm

Min. scale value

0.5HRN(T)

Dimensions

466 x 238 x 630mm

Weight

approx. 65kg

Power

AC220V/50HZ/60HZ

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Certifications

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Packaging & Shipping

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Company Information

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

Our Services

NADE HRD-45 Motorized Superficial Rockwell hardness tester Price for ferrous metals, alloy steel, carbide

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
