GY-4 Fruit Hardness Tester

Seaming Chuck  Diameter: Φ11.1mm/Φ7.9mm
Measurement Range: 0.2～15 Kg/cm2 (×105 pa)/0.4～30 Kg/cm2
(×105 pa)
Division Value: 0.01 Kg/cm2
Availability:
Inquire

  • GY-4

  • Charging 100-240V/AC;Battery continuous working time: 8 ~ 10 hours.

  • 1

  • 1 year

  • China

Product Description

GY-4 application

The fruit hardness tester has advantages of high precision,easy operation and carry.It can store data and input data to computer for statistical,It can be used together with a special test stand to increase measurement accuracy.

ND series fruit hardness tester has many specifications for the user to choose, users can choose the appropriate specifications of the instrument according to the load of the required test product force. The scientific use measurement range is 10% to 100% of full scale. The measurement department does not recommend using less than 1% of full scale.


Features

GY-4 detail

1. High-precision and high-resolution: LCD display, backlight function (backlight for night use), and screen number can reverse ;

2. Display battery capacity: 3 grid, 2 grid, 1 grid, automatic shutdown when the power is too low.
3. Setting function of gravity acceleration:users can input at your option the accurate value of gravity acceleration at the using place so as to make the testing and unit conversion be more accurate.
4. Function of peak value maintaining.Maintain the display of peak value until manually cleared to Zero.
5. Automatic peak function:Maintain the display of peak value for 10 seconds and then release automatically.
6. Data storage function.447 testing values can be stored.
7. Data output function.The data can be input into computer through data line for various analyses.
8. Automatic shutdown time setting: automatic shutdown time setting can be set for 10 minutes to 90 minutes automatically shutdown; 10 minutes no operation automatic shutdown,10 minutes for the default, the automatic shutdown can be set to the required automatic shutdown time, automatic shutdown set to 0, will not automatically shutdown.
9. High quality chargeable power supply,the charging voltage is available from 100V to 240V,which can accommodate most areas in domestic and at abroad.
10. 2 sets mounting dimensions,it is applied for most testing platforms domestic and foreign,easy for users to install it to platform.


Specification

Model

GY-4

Unit

Kg/cm2(×105 pa)

Seaming

Chuck  Diameter



Φ11.1mm



Φ7.9mm

Measurement
Range

0.2～15 Kg/cm2 (×105 pa)

0.4～30 Kg/cm2
(×105 pa)

Division Value

0.01 Kg/cm2

Indication Error

±0.5%

Accuracy

±1%

Depth Pressed
by
Seaming Chuck



10mm



Power

Charging 100-240V/AC;Battery continuous working
time: 8 ~ 10
hours.

Power
Supply   Mode


AA NI-MH battery /220V AC charging 4 ~ 6 hours.

Stability

Temperature drift
0.2uV/℃（0-60℃）;Zero drift ≤ 0.1%/8
hours/FS

Working
Temperature



5℃～35℃

Relative
Temperature



0～+60℃

Relative Humidity

15％～80％RH

Working
Conditions

No hypo center and corrosive medium

Net Weight

450g

Outline Dimension

230×66×36mm
