NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

  • Vacuum Drying Equipment

  • 3kg

  • Medicine Processing, Chemicals Processing, Food Processing

  • New

  • China

  • Nade

  • 220V 50HZ

  • 1.1KW, 1100w

  • 380mm*650mm*360mm

  • CE Certificate

  • Easy to Operate

  • 1 Year

  • 15

  • No service

  • Other

  • None

  • None

  • Ordinary Product

  • Not Available

  • Not Available

  • 1 Year

  • Other

  • Engineers available to service machinery overseas

  • TF-FD-1(multi-pipeline top-ptess)

  • 0.07㎡

  • 3Kg/24h

  • <15Pa(no load)

  • <-50℃

  • 380mm*650mm*360mm

  • 15kg

Product Description

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Normal Lyophilizer/freeze drying equipment/freeze dryer

Product Description

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

The laboratory lyophilizer series include ordinary type, cover type, branch manifold type, and T fixture, which are suitable for the freeze drying thermosensitive substances, such as serum, plasma, antibody, vaccines, drugs and microorganism, the plant extracting for bioresearch, and drying nano-particles, colloid, power, foods, plants and cultural relics in non-biological field.

The full name of the lyophilizers are freeze dryer, also called refrigerated dryer. They can be sorted into two fields: laboratory and industry according to application.

The TF-FD laboratory lyophilizers series are in the field of the biological laboratory products. The freeze-drying technology is mainly be used in the drug production of serum, plasma, vaccine, enzyme, antibiotic, hormone, etc. The freeze-drying technology can be used in the medicine inspection of biochemistry, immunology and bacteriology. It can also be used in blood, bacteria, artery, skeleton, skin, cornea, nerve tissues, the long-stem storage of organs, etc.

The TF-SFD production square lyophilizers series are large-scale lyophilizers which are used in industrial production. The equipment has good temperature stability and freeze-drying effect. The pre-freeze dry is preceded in situ, which can reduce the complex operation of the drying process to realize freeze-drying automatically. Square lyophilizers are mainly used in industrial processing, such as food dehydration, soup bases, vegetables, instant food, instant, meat, etc.

Feature

The equipment is adopted with imported all-seal refrigerant compressor with low temperature and high capturing water capability. The machine can be cooled down by air, instead of water.

Vacuum connection is adopted with international standard parts, which is easy to dismantle or install and has reliable sealing performance.

Cold trap temperature and sample vacuum are both used LED digital to display, which is brief and clear.

The touching soft key which is specifically designed can set various functions fast and accurately. The operation is easy and convenient.

The transparent bell-type drying room is natural heating, safe and visual.

The stainless steel sample holder is designed specially. Normal sample tray is space adjustable and the layers can be set freely.

The stainless steel cold trap and mesa is clean, hygeian, beautiful and corrosion resistant.

Application:

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

Specification

1.1 Model TF-FD-1(multi-pipeline top-ptess)

1.2 Condensing Temperature <-50℃

1.3 Vacuum <15Pa(no load)

1.4 Freeze-dried Area 0.07m2

1.5 Capturing Water Capability 3Kg/24h

1.6 Sample Plate Φ180mm×3 layers

1.7 Power Supply Requirements 220V 50Hz

1.8 Power 1100W

1.9 Dimension 380mm×650mm×360mm

1.10 Eggplant Shaped Bottle 50ml,100ml,250ml,500ml,1000ml can choose 8 eggplant shaped bottles

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

Certifications

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

Packaging & Shipping

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

Our Services

Please contact us by alibaba message or TEL: +0086-571-88064952 for any requirements or questions. There may be a time zone difference depending on your location, but we will respond to you as soon as we can.

We cherish every opportunity to serve our customer! It will be our great pleasure to do business with you and hope it will be a win-win situation for both of us.

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

Company Information

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

NADE TF-FD-1 Multi-pipeline Top-ptess Laboratory Lyophilizer/freeze drying equipment/freeze dryer

FAQ

Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.


Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.


Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.


Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.

Please send your request details to us by clicking "send" at the bottom!
