NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

  • Zhejiang, China
  • NADE
  • solidifying point at -60℃~10℃
  • 0.1℃
  • Temperature difference ≥65℃
  • 15min temperature difference≥60℃
  • (4.9*10~49*105)Pa
  • 1.5L/min
  • ≤85%
  • 250W
  • 460mm*360mm*470mm
  • 26Kg

Product Description

Product Description

SYD-510Z-1 Automatic Solidifying Point&Pour Point Tester is made as per standards GB/T 510,ASTM D852 Standard Test Method for Solidifying Point of Petroleum Products, GB/T3535,ASTM D97 Standard Test Method for Pour Point of Petroleum Products. It is a kind of high automatic instrument with advanced design. It is used to determine the solidifying point and pour point of light oils which have good flow ability and low viscosity such as gasoline, light diesel oil and transformer oil. It can be widely used in oil refineries, oil stations and other relevant institutions.

Feature

1. It adopts SCM as the core control system. Colored touch screen. It can track and display the real-time temperature, and simulate the test status intelligently.

2. It adopts high accuracy detecting sensor and semiconductor refrigeration technology. The test precision is high.

3. It uses little mass of oil sample. The test is rapid(5~10 min for one test). The test procedures are completed automatically are injecting the sample. It has good stability and repeatability. The result is reasonable. The test result can be printed after test.

4. The instrument needs less sample for the determination. The intelligence is high. It can do the test automatically after the sample is added. A micro-printer is equipped.

Specification

Model

SYD-510Z-1

Applicable oils

The oils with solidifying point at -60℃~10℃

Precisionr

±1℃ (HWY-15 Low-temperature circulatory water bath when the solidifying point is lower than -50℃ )

Display resolution

0.1℃

Maximum cooling depth

Temperature difference ≥65℃

Cooling speed

15min temperature difference≥60℃

Requirement for cooling water

Pressure

(4.9×10~49×105)Pa

Flow rate

1.5L/min

Power supply

AC220V±22V,50Hz

Maximum power consumption

250W

Sample dose

20ml per time

Working environment

Ambient temperature:(25±10)℃, RH <85%

Dimension

460mm×360mm×470mm

Net weight:

26Kg

Optional accessories

Low temperature water bath:HWY-15 Low-temperature circulatory water bath

Other models:

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

SYD-510-1 SYD-510F1 SYD-510G

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

SYD-2430A SYD-2430W SYD-3535Z

Packaging & Shipping

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

Company Information

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

Our Services

NADE SYD-510Z-1 Laboratory Low Temperature Automatic Solidifying Point and Pour Point Tester of petroleum products

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
