NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus

  • China
  • NADE
  • SYD-2806A
  • height:6.4mm,Upper aperture:19.8mm,Lower aperture 15.9mm
  • Diameter is 9.5mm,Weight is(3.50±0.05)g
  • Inner ring is 23.0mm,center is 9.55mm
  • 2 samples, parallel test
  • 25.4mm from bottom
  • 1000ml beaker
  • Mercury-in-glass thermometer,range 30℃~180℃ Division is 0.5℃
  • 1.5kg

Product Description

Product Description

The instrument is designed and made as per GB/T4507 and ASTM D36 Test Methods for Softening Point of Petroleum Asphalt of national standard of People’s Republic of China , T0608 Asphalt Softening Point Test (Ring-and-Ball Apparatus) in the Industrial Standard of People’s Republic of China JTJ052 Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering. It is suitable to determine softening point of petroleum asphalt, coal pitch, liquid petroleum asphalt, and various asphalts. It can be widely used for asphalt manufacturing companies, highway and bridge construction companies, relative colleges and universities, and scientific research institutes.

Specification

Model

SYD-2806A

Ring

The height is 6.4mm,Upper aperture is 19.8mm,Lower aperture 15.9mm

Ball

Diameter is 9.5mm,Weight is(3.50±0.05)g

Ball locating ring

Inner ring is 23.0mm,center is 9.55mm

Test method

2 samples, parallel test

Support plate

25.4mm from bottom

Vessel

1000ml beaker

Thermometer

Mercury-in-glass thermometer,range 30℃~180Division is 0.5

Net weight

1.5kg

Notes:

1. The reagent and equipments for installing the instrument are supplied by end-users themselves.

2. The softening point thermometer needs to be purchased by the end-user. Parameters: 30 ℃ ~ 180 ; scale is 0.5 .

3. The usage,management and saving of poisonous and harmful reagent,pls operate according to the relative principle.

4.PLS read the operation manual and industry standard before using the instrument.

Other models:

SYD-2806F SYD-2806G SYD-2806H

Packaging & Shipping

NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus

Company Information

NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus

NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus

Our Services

NADE SYD-2806A Laboratory Semi-automatic Asphalt/Bitumen Softening Point Tester/Apparatus

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
