WRR / WRR-Y
NADE
1
CHINA
Product Description
A melting point apparatus is a precision instrument used to determine the melting point of a substance. By precisely controlling the temperature and observing the phase transition of the substance from solid to liquid, the melting point range can be determined.
• To be used to measure the melting point of medicines, dye-stuffs and perfumes and other organic crystal substances to determine their purity.
• Visually detect the initial and final melting points of the sample.
• Measuring three samples at the same time and calculate the average value automatically.
• Use silicone oil or water as heating-conducting medium.
Applications
• Pharmaceutical Industry: To inspect the purity of samples.
•Chemical Industry: To assist in identifying unknown compounds and determining the thermal stability of substances through melting point determination. （*Model WRR-Y Visual Melting-point Apparatus can measure the purity of active pharmaceutical ingredients and finished pharmaceutical products.）
• Food and Cosmetics Industry: To determine whether certain ingredients in food additives or cosmetics meet the standards.
Specifications
Parameters/Model | WRR | WRR-Y |
Measuring range | Silicon oil : 40℃-280℃ | Water：40℃-90℃ Silicon oil：60℃-280℃ |
Heating-conducting medium | Silicon oil | Water / Silicon oil |
Measuring mode | Visual (8x magnification window) | |
Resolution | 0.1℃ | |
Linear heating-up rate | 0.5℃/min, 1.0℃/min, 1.5℃/min, 3.0 ℃/min | |
Accuracy | ≤200 ℃：±0.4℃；＞200 ℃：±0.7℃ | |
Repeatability | 0.3℃ (heating rate: 1.0℃/min) | |
Linear heating rate error | ±10% | |
Capillary dimensions | Outer diameter: φ1.4mm ; Inner diameter: φ1.0mm ; Length: 120mm | |
Number of capillary | 3 | |
Height of sample | 3mm | |
Interface | RS232，USB | |
Display | LCD | |
Power supply | 220V±22V，50Hz±1Hz，200w | |
Overall Dimension | 390mm ×390mm ×520mm | |
Weight(Gross) | 13kg | |
