NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

  • Zhejiang, China
  • 400~700nm full spectrum LED light source
  • HAZE, Transmittance(T)
  • 0/d
  • 21mm and 7mm
  • 0-100%
  • 0.01
  • ≤0.1
  • dia 154mm
  • Mass Storage, unlimited
  • USB

Product Description

Product Description

It is designed for plastic sheets, films, glasses, LCD panel, touch screen and other transparent and semi-transparent materials haze and transmittance measurement. Our haze meter does not need warm-up during test which saves customer's time. Instrument conforms to ISO, ASTM, JIS, DIN and other international standards to meet all customers’ measurement requirement.

Application

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

Mobile Device Cover Phone Film

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

Plastic Film Glasses

Feature

1). It conforms to both ASTM and ISO international standards ASTM D 1003,ISO 13468,ISO 14782, JIS K 7361 and JIS K 7136.

2). Instrument is with a calibration certification from a third party laboratory.

3). No need to do warm-up, after instrument is calibrated, it can be used. And measurement time is only 1.5 seconds.

4). Three kinds of illuminants A,C and D65 for haze and total transmittance measurement.

5). 21mm test aperture.

6). Open measurement area, no limit on sample size.

7). It can realize both horizontal and vertical measurement to measure different kinds of materials such as sheets, film, liquid, etc.

8). It adopts LED light source whose lifetime can reach 10 years.


Specification

Model

Upgrade Haze Meter TH-110

Character

ASTM D1003/D1044 and ISO13468/ISO14782 standard for haze measurement and light transmittance measurement.

Open measurement area and samples can be tested vertically and horizontally. Application: glass, plastic, film, display screen, packaging and other industries.

Illuminants

D65,A,C

Standards

ASTM D1003/D1044, ISO13468/ISO14782, GB/T 2410,JJF 1303-2011, CIE 15.2, GB/T 3978, ASTM E308, JIS K7105, JIS K7361, JIS K 7136

Test Parameter

ASTM and ISO (HAZE),Transmittance (T)

Test Apertures

21mm and 7mm

Instrument Screen

7 inches touch screen with Android Software

Haze Repeatability

Φ21mm aperture,Standard Deviation: within 0.05(when a haze standard with value 40 is measured 30 times at 5-second interval after calibration)

Transmittance Repeatability

≤0.1 unit

Geometry

Transmittance 0/D (0 degree illumination, diffused receiving)

Integrating Sphere Size

Φ154mm

Light Source

400~700nm full spectrum LED light source

Test Range

0-100%

Haze Resolution

0.01 unit

Transmittance Resolution

0.01 unit

Sample Size

Open space, no size limit

Data Storage

Mass Storage, unlimited

Interface

USB

Power Supply

DC12V (110-240V)

Working Temperature

+10 – 40 °C (+50 – 104 °F)

Storage Temperature

0 – 50 °C (+32 – 122 °F)

Size

L x W x H:310mmX215mmX540mm

other models:

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

TH-09 TH-100

Packaging & Shipping

Our Packaging Details:

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

Our Shipping

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

Our Services

Please contact us by alibaba message or TEL: +0086-571-88064952 for any requirements or questions. There may be a time zone difference depending on your location, but we will respond to you as soon as we can.

We cherish every opportunity to serve our customer! It will be our great pleasure to do business with you and hope it will be a win-win situation for both of us.

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

Company Information

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

NADE High precision digital Haze Meter TH-110 with 7 inches touch screen

FAQ

Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.


Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.


Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.


Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
