NADE Double Beam UV Vis Spectrophotometer UV-2601

  • 1 YEAR


  • Zhejiang, China

  • NADE

  • UV-2601

  • 630*470 *210mm

  • 26kg

  • N/M

  • 190nm-1100nm

  • ±0.3nm

Product Description

NADE Double Beam UV Vis Spectrophotometer UV-2601


1 Wide wavelength range, satisfying requirements of various fields

2 Five options for spectral bandwidth selection, 5nm, 4nm, 2nm, 1nm and 0.5nm, made according to customer's need and satisfying the requirements of pharmacopoeia

3 Fully automated design, realizing the simplest measurement

4 Optimized optics and large scale intergrated circuits design, light source and receiver from world famous manufacturer all add up to high performance and reliability

5 Rich measurement methods, wavelength scan, time scan, multi-wavelength determination, multi-order derivative determination, double-wavelength method and triple-wavelength method etc., meet different measurement requirements

6 Automatic 10mm 8-cell holder, changeable to automatic 5mm-50mm 4-position cell holder for more choices

7 Data output can be obtained via a printer port and a RS-232 interface (RS-485 and USB port optional)

8 Parameters and data can be saved for user's convenience

9 PC controlled measurement can be achieved for more accurate and flexible requirement


Wavelength Range: 190-1100nm

  • Spectral Bandwidth: 2nm (5nm, 4nm, 1nm, 0.5nm optional)
  • Wavelength Accuracy: ±0.3nm
  • Wavelength Reproducibility: ≤0.15nm
  • Optical System: Double beam
  • Photometric Accuracy: ±0.3%T(0-100%T), ±0.002A(0-1A)
  • Photometric Reproducibility: ≤0.15%T
  • Working Mode: T, A, C, E
  • Photometric Reproducibility: -0.3-3.5A
  • Stray Light: ≤0.1%T(NaI, 220nm, NaNO2 340nm)
  • Baseline Flatness: ±0.002A
  • Stability: ≤0.001A/h( at 500nm, after warming up)
  • Noise: ±0.001A( at 500nm, after warming up)
  • Display: 6 inches high light blue LCD
  • Detector: silicon photo-diode
  • Power: AC 220V/50Hz, 110V/60Hz, 180W
  • Dimensions: 630×470× 210 mm
  • Weight: 26kg
