GRX Series
NADE
1
CHINA
Product Description
Features:
1. Table type, heating on the back, horizontal force convection. Adopte imported fan, input and output volume can be adjustable，assure the temperature within the working chamber even.
2. Working chamber is made of high quality corrosion-resistant stainless steel. The shell is made of high quality steel plate, surface processing with static spraying plastic.Dual-layer toughened glass observation window. The shelf is made of stainless steel, and can be adjustable. It is easy and convenient to use. With a beautiful and novel appearance.
3. Temperature controllor adopt high speed, high performance CPU handling chip. High sensitive, high precision platinum resistance sensor. Have fixed programme control function of “Resume By Alarm”, “ Close By Alarm”, “Working By Alarm”. Timing time is 0-99Hours.
4. Temperature controllor is with sensor malfunction alarm, low/high temperature deviation alarm. Over-temperature alarm. Parameters memory. Temperature display emendation. Self-diagnosing dynamic control technology.
5. have 10 segments programs of temperature-controlling, realize temperature’s curved programme operation.
6. Independent alarm system for temperature-limiting ensures experiments run safety and no accident would happen. (Option)
7. Equipped with the interface of inert gas and flow meter of inert gas. (Option)
Specifications
Model | GRX-02A | GRX-05A | GRX-12A | GRX-20A | |
Chamber volume (L) | 25 | 50 | 105 | 200 | |
Environmental condition | Temperature 5～30℃ | ||||
Maximum relative humidity 80% | |||||
Altitude up to 2000m | |||||
Method | horizontal forced convection | ||||
Power | AC220V,50Hz | ||||
Range | Rt +10℃～200℃ | ||||
Temperature | Resolution | 0.1℃(≤100℃) ，1℃ （>100℃） | |||
Pulse degree | ±1℃ | ||||
Uniformity | ±2℃ at 100℃ | ||||
controller | (The PID microprocessor controls,touch type,digital display) | ||||
Sensor | PT100(Platinum gold resistor PT100) | ||||
Timer | Setted to start or stop: 1min to 99 hours | ||||
Material | Internal | (304 stainless steels) | |||
External | 08F(Iron 08F) | ||||
Dimension(mm) | Internal | 300×300×275 | 420×350×350 | 550×350×550 | 600×550×600 |
External | 580×470×445 | 710×520×520 | 830×530×720 | 880×740×790 | |
Net weight | 30KG | 43KG | 59KG | 77KG | |
Consumption power | 650W | 940W | 1740W | 2290W | |
Shelf dimension(mm) | 246×280 | 366×340 | 496×340 | 546×540 | |
Shelve(supply/most) | 2/4 | 2/6 | 2/12 | 2/9 | |
