GRX-9023A
NADE
220V/110V 50HZ/60HZ
1
1
CHINA
Product Description
Features
1. Digital display microcomputer temperature controller with timing function, precision and reliable temperature control.
2. Quickly temperature rise, forced convection, drying and hot air can directly pass through the heated object for dry and sterilization, which apparently shortening the time.
3. The equipment can automatically break off, if limited temperature is exceeded, to ensure safety.
4. Adjustable ventilation door, spacing the shelves can be arbitrarily adjusted.
Specification
Model | GRX-9023A | GRX-9053A | GRX-9073A | GRX-9123A | GRX-9203A | GRX-9403A | GRX-9603A |
Voltage | AC 220V/50Hz | 380V/50HZ | |||||
Temperature range | RT+10℃~300℃ | ||||||
Temperature resolution | 0.1℃ | ||||||
Temperature fluctuation | ±1℃ | ||||||
Operating ambient temperature | +5~40℃ | ||||||
Input power | 870W | 1120W | 1570W | 2070W | 2470W | 3300W | 4200W |
Inner dimension(mm) | 340*325*320 | 420*395*350 | 400*450*450 | 550*450*550 | 600*600*650 | 600*550*1300 | 800*600*1300 |
Outline dimension(mm) | 620*490*490 | 720*590*520 | 740*590*630 | 840*570*730 | 880*750*825 | 780*760*1800 | 980*800*1800 |
Carrier (standard configuration) | 2pcs | 3pcs | 4pcs | ||||
Timing range | 1-9999 minutes | ||||||
remark | Imported motor | ||||||
Pic |
| ||||||
Conditions of no-load performance test: ambient temperature: 20℃, and ambient humidity: 50%RH.
