PH600L Benchtop PH Meters

pH Range: -2.000 to 20.000 pH
mV/ORP Range: -2000.00 to 2000.00 mV
Temp Range: -5 to 130 ºC
Data Storage: 1000 Groups
Availability:
  • PH600L
  • AC Adapter, 100-240V AC input, DC24V output
  • 1
  • 1 year
  • China

Product Description

PH600L

● Color High contrast LCD touchscreen, 7.0 inches.

● Intelligent operation system provides features including user management, calibration management, method management, data management and etc.

● Multi-reading feature allows auto-read, timed-read and continuous-read.

● Automatic/Manual temperature compensation ensures accurate results.

Data Storage 1000 sets for each parameter (GLP-compliant).

● Data analysis feature helps user review, compare and recalculate results.

● Support for USB or RS-232 communication.

● Reset feature automatically resumes all settings back to factory default options.

● IP54 waterproof.

● 1-6 points calibration with Standard Recognition.

● Selectable pH buffer groups, including NIST, DIN, GB.

● Support for pH standard group customization.

● Automatic electrode diagnosis with pH slope and offset display.


Application

PH measurement is widely used in universities, environmental protection, medicine, food, health, geological prospecting, metallurgy, marine exploration and other fields. It is required for common acid rain detection, surface water, industrial wastewater, drinking water, beverages, daily chemical products, textiles, etc.

 Ph meter application 1pH meter application 2.jpg

Detailed Examples:

1. The PH value of meat is related to the freshness of meat. By detecting the PH value of meat, we can judge the shelf life of meat and the nature of meat.

 pH meter application 3

2. When the beverage is within the proper PH range, it is conducive to ensuring the good taste and stability of the juice.

pH meter application 4

3. PH value measurement is a very important test item in the pharmaceutical process, and it is also one of the important tools for the detection of mobile phase buffer system in drug liquid phase analysis. Refer toChinese Pharmacopoeiafor PH test basis.

pH meter application5

4. The main component of MSG is sodium glutamate, with a PH value of about 7.

pH meter application 6

5. PH value is a mandatory inspection item for canned products.

pH meter application7

6. PH measurement is a very important experiment in the cosmetics industry. Face cream, hair dye and other daily chemical products have pH requirements.

pH meter application 8

Contact us to know more application solutions, NADE company will recommend suitable pH meter with ph sensor.


Specification

Model

PH600L

Parameters

pH/Temp.(mV/ORP)

             pH

Range

-2.000 to 20.000 pH


Resolution

0.1, 0.01, 0.001pH


Accuracy

±0.002 pH


Calibration Points

Up to 6


Standard Customization

Yes


Calibration Reminder

Yes


Standard Recognition

NIST, GB, DIN buffers


Slope Limit

Yes

        mV/ORP

Range

-2000.00 to 2000.00 mV


Resolution

0.1, 0.01 mV


Accuracy

±0.03%FS

     Temperature

Range

-5 to 130 ºC


Unit

ºC


Resolution

0.1


Accuracy

±0.1

    Measurement

Reading Mode

Auto Read (Fast, Medium, Slow), Timed, Continuous


Reading Prompts

Reading, Stable, Locked


Temp. Compensation

ATC, MTC

  Data management

Data Storage

1000 Groups


GLP Features

Yes


Log Management

Yes

             Inputs

pH Electrode

BNC(Q9)


Temp. Probe

6-pin Mini-DIN

           Outputs

USB, RS 232

USB 2.0 flash memory device, printer, PC

     Display options

Backlight

Yes


Auto Shutdown

1~60 min, off


IP Rating

IP54


Date and Time

Yes

           General

Power

AC Adapter, 100-240V AC input,

            DC24V output


Dimensions

280×280×130 mm


Weight

2500g (5.51 lb)
