Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

  • 1 year

  • Laboratory Thermostatic Devices

  • other

  • Nade

  • HNY-102T

  • China

  • 280L

  • 1600W

  • 5℃-30℃

  • one(per unit)

  • ambient +10°Cto 65°C(No refrigeration)

  • convolution

  • P.I.D microprocessor chip

  • forced convection

Product Description

Nade Superposition of constant temperature incubator shaker HNY-102T

Product Description

Pull out rail platform. It can easily pull the platform out to load or unload fixtures and then push it back and lock, which is fast and convenient to operation.

Three stackable layers structure. Each layer can be independently controlled. Temperature, speed and time can be set alone. Users can run any layer according to need.

Note: stackable incubator shaker would be optional high temperature incubator shaker (temperature up to 80 ℃); Humidifying incubator shaker.

High pressure water rinses the bottom of the chamber and platform. Simple cleaning, fast and efficient.

Advanced USB data automatic record, download and processing system. It has large storage, and automatic recording & saving in the full test processing. The data could be directly downloaded by USB or automatically downloaded by wireless.

Automatic analyzing, listing table, charting and printing on downloaded dates. It can trace back to the whole process of experiment in order to optimize the reaction conditions and choose the test method to confirm the experiment process.

Specification

model

HNY-102T

specifications

control model

P.I.D microprocessor chip

convection model

forced convection

shake model

convolution

display

LCD

Drive mode

Multidimensional drive

system of USB data download and analysis

Yes

control system

Multiple Programmable mode(temp,speed,time)

cyclotron frequency range(rpm/min)

0;20-350(top floor 20-300)(To do static culture)

cyclotron frequency sensitivity(rpm)

±1

Orbit Diameter(mm)

Φ26

maximum capacity

250ML×60 OR 500ML×40 OR 1000ML×20OR 2000ML×15(per unit)

standard capacity

500ML×40

size of platform(mm)

830×510

timing range(h)

0-9999(Any time,continuous duty)

temperature range(℃)

ambient +10°Cto 65°C(No refrigeration)

temperature sensitivity(℃)

±0.1

temperature uniformity(℃)

≤0.8(37℃)

temperature uniformity(℃)

≤0.1(37℃)

number of platform

one(per unit)

outside dimension(W*D*H)(mm)

1360×830×620(per unit)

capacity(L)

280

power(W)

1600

power supply

AC220±10%50-60HZ

outside temperature(℃)

5-30

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

Certifications

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

Packaging & Shipping

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

Company Information

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

Our Services

Nade Superposition of constant temperature laboratory incubator shaker HNY-102T

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
