Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

  • 1 year
  • Laboratory Thermostatic Devices
  • other
  • Nade
  • HNY-303
  • China
  • 1400W
  • 250ML*15
  • one
  • ambient Cto 100°C(No refrigeration)
  • HNY-303
  • P.I.D microprocessor chip
  • Reciprocate
  • 0-999H
  • LCD liquid-crystal display
  • Track drive

Product Description

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

Product Description

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

1,Advanced USB data automatic record, download and processing system. As well as it has large storage, and automatic recording & saving in the full test processing,

2,The data could be directly downloaded by USB in a minute or automatically downloaded by wireless, without the hassle of moving computers and replacing printing papers.

3, Automatic analyzing, listing table, charting and printing on downloaded dates. Easy replay the data by clicking the mouse; it can trace back to the whole process of experiment in order to optimize the reaction conditions and choose the test method to confirm the experiment process.

4, Multi-steps rotate speed, temperature and time control systems. Different rotational speed, temperature and time can be set at one time; operation model can be automatically converted during operation (touch screen only).

5, The ultra low speed starts, startup speed is adjustable. If the speed out of control, it will be locked automatically.

6, high-precision speed control: PID feedback control, the motor speed is stable and accurate, the accuracy of ± 1RPM

7,high-precision temperature control: PID feedback control, the measurement accuracy of 0.1 ° C, the measured temperature deviation from the set value ± 3 ° C, audible and visual alarm

8,Unique drive system makes the machine running smoothly, stably, durably and reliably.

9,Intelligent sound and light alarm environmental scanning micro-processing controller, the machine has the functions of automatic stop protection by opening the door, self-diagnostic, and security alarm.

10,Big backlight LCD screen with Chinese subtitles, man-machine dialogue prompts, and displaying measured values, settings and machine operation.

11,The operating parameters can be memorized and protected. Unexpected power outage, the original set-up process can be automatically resumed.

12,The operating parameters are encrypted and locked, which can avoid human errors. The machine has the functions of Light and ultraviolet disinfection.

13,Automatic power protection devices when the motor is overheating or the temperature is out of control

14,The machine can run continuously or be timing. It can display the set time and time remaining

15,A unique slow-start design, preventing the shake-flask liquid splashing caused by a sudden start, effectively guaranteeing the accuracy of quantitative experiments

16,Three layers structure, over an area of an area small, the large using space.

17,Each layer can be independently controlled. Temperature, speed and time can be set alone. Users can run any layer according to need.

18,Clock and date can be displayed (touch screen only).

Specification

model

HNY-303

specifications

control model

P.I.D microprocessor chip

shake model

Reciprocate

display

LCD liquid-crystal display

Drive mode

Track drive

system of USB data download and analysis

yes

control system

30 segments temperature, speed, time, control system

cyclotron frequency range(rpm/min)

0;20-300(To do static culture)

cyclotron frequency sensitivity(rpm)

±1

Orbit Diameter(mm)

26

maximum capacity

100ML×24 OR 250ML×15 OR 500ML×11 OR 1000ML×6

standard capacity

Spring net box

size of platform(mm)

498×316

timing range

0-9999h/min(Any time,continuous duty)

temperature range(℃)

ambient Cto 100°C(No refrigeration)

temperature sensitivity(℃)

±0.1

temperature uniformity(℃)

≤0.1

number of platform

one

outside dimension(W*D*H)(mm)

640×620×550

power(W)

1400W

power supply

AC220±10%50-60HZ

Net weight(kg)

70

Gross weight(kg)

90

other functions

ultra-low speed start, adjustable start speed, overspeed auto-prtection, watch dog timer, parameters Storage, encryption parameters, electricity incoming recovery,function of lighting and UV disinfection (optional)

Certifications

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

Packaging & Shipping

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

Company Information

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

Our Services

Nade HNY-303 Laboratory Thermostatic Water Bath Shaker

FAQ
Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.

Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.

Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.

Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
