NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

  • 1 year

  • /

  • China

  • Nade

  • V4.0

  • 100-8000mbar (115psi)

  • mbar

  • Ambient Temperature:+5℃ ~ +40℃;Relative Humidity:10-80%

  • Built-in printer

  • 500 sets

  • 5.7 TFT,Single color

  • RS232

  • Chinese/English

  • Online/Offline

  • 7.5KG

Product Description

Product Description

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

The V4.0 Integrity Tester is compact, handy to use, and fully automated integrity test instrument,which performs bubble point,diffusion flow,enhanced bubble point, and water-based test for hydrophobic filters.

Features:

1. The scientific electronic signature and classification to distinguish the responsibility easily, and to prevent false operation.

2. Display of test data and curves in real time, monitoring the whole process of testing.

3. Provides automatic printing set function, the user can operate more simple and convenient.

4. Water Based test (WH) for Hydrophobic Filter: using purified water as test liquid instead of IPA and Ethanol, thus it can avoid trace quantity of ethanol or IPA contamination when testing filters.

5. The instrument can store 500 history record and curve.

Specification:

Power Supply

100–260 VAC, 50HZ, 120W ;

Operation pressure

100-8000mbar (115psi) ;

Unit

mbar

Operation Condition

Ambient Temperature:+5℃ ~ +40℃;Relative Humidity:10-80%

Dimension(mm)

400(Depth)*240(Width)*270(Height1)*220(Height2)

Test Function

Manual Bubble point Test;Basic Bubble Point Test;Extensive Bubble Point Test;Diffusion Flow Test;Water Immersion Test;

Test Accuracy

Upstream Volume:±4%;Bubble Point:≤± 50mbar ;Diffusion Flow Test:≤± 4% ;Water Immersion Test:≤± 0.05ml

Test Scope

Bubble Point :590-6900mbar Diffusion Flow Speed:1-180ml/min WI:0.01-30ml/min

Applied Range

Symmetric and asymmetric membrane test, needle filter, filter bag, flat filter, filter cartridge (3 core within 20 inches)

Print Function

Built-in printer;

Historical Records

500 sets;

Display Screen

5.7″TFT,Single color;

Serial Connection

RS232;

Language

Chinese/English;

Work Mode

Online/Offline;

Applicable Environment

Above D level;

Weight

7.5KG;

Applied range:

Disc Membrane:Φ25mm-Φ300mm;

Standard Cartridge:2.5″- 40″

Capsule & Mini Catridge

Air filter test :2.5″- 40

More Products:

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

V6.5 V8.0

Packaging & Shipping

Our Packaging Details:

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

Our Shipping

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

Our Services

Please contact us by alibaba message or TEL: +0086-571-88064952 for any requirements or questions. There may be a time zone difference depending on your location, but we will respond to you as soon as we can.

We cherish every opportunity to serve our customer! It will be our great pleasure to do business with you and hope it will be a win-win situation for both of us.

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

Company Information

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

NADE Filter Integrity Tester Integtest V4.0 Bubble Point Filter For Diffusion Flow Test And Water Immersion Test

FAQ

Q: How long is the delivery time?
A: 7-15 working days after we received your payment or order confirmed.


Q: What is the warranty for the equipment?
A: One year. We can provide you lifelong technical support.


Q: What is the payment terms?
A: T/T, L/C, Western Union, etc.

Q: What after-sales service can be provided by Nade ?
A: The after-sales service of Nade is divided into two parts: technical support and maintenance.


Q: What about the technical support and maintenence?
A: Sometimes users will get some problems when they operate the instruments which are unfamiliar or first time use, users can send us emails or call us about detailed information. We will provide users solution or operation video.For so many years’ experience, our instruments works well during warranty period. If there any parts are broken during warranty period, we would like to provide spare parts for free.
