NADE D3024 200~15000rpm laboratory high speed micro clinical centrifuge machine

Share to:

NADE D3024 200~15000rpm laboratory high speed micro clinical centrifuge machine



Inquire

Classification:
Laboratory Centrifuge
Brand Name:
NADE
Model Number:
D3024
Place of Origin:
China
Weight:
12kg
Max. Speed [rpm]:
15000rpm
Speed Accuracy [rpm]:
±20 rpm
Run Time:
30sec-99min-HOLD (Continuous operation)
Driving Motor:
Brushless DC motor
Noise level [dB]:
≤64

Product Description

Product Description

NADE high speed D3024 micro clinical hematocrit labatory centrifuge

Introductions

High speed micro-centrifuge range is widely used in physical and chemistry analysis, biochemistry, cellular and molecular biology, clinical Labs and blood donation centers, and is ideal for high-end research applications:

- Sedimentation of cells and viruses

- Separation of sub-cellular organelles

- Isolation of macromolecules such as DNA, RNA, proteins or lipids

Features:

1.Cast iron chassis with low gravity, provides stable and reliable running at maximum speed;

2.Special multi-flow air cooling design helps keep lower rotor temperature;

3.Unique temperature display protects sensitive samples;

4.Multi voltage design with high speed accuracy and reliable running;

5.Quiet and stable operation for the lab;

6.Gentle braking at low speed with efficient separation;

7.Brushless DC motor accelerates quickly and effortlessly to the set speed with high accuracy of speed in ±20 rpm.

Function:

1.Operation can be timed from 30 seconds to 99 minutes or used in continuous mode;

2.The short spin function is used for quick spins by pressing and holding PULSE key. The centrifuge speed can be accelerated and held at the target speed;

3.Automatic release of lid when the rotor stops to save processing time;(excluding D3024R)

4.Easy-to-read display and sound alerts;

5.Both RPM or G-force can be set and displayed.

Specification:

	D3024
Max. Speed [rpm]	15000rpm (200-15000rpm), increment:10rpm
Max. RCF [×g]	21380×g, increment:10×g
Speed Accuracy [rpm]	±20 rpm
Rotor Capacity	5ml×18; 0.2ml/0.5ml/1.5ml/ 2ml×24; 0.5ml×36; PCR8×4
Run Time	30sec-99min-HOLD (Continuous operation)
Driving Motor	Brushless DC motor
Safety Devices	Dual door interlock, Over-speed detection; Over-temperature detection; Automatic internal diagnosis
Power	Single-phase, AC220V-240V, 50Hz/60Hz, 5A; AC110V-120V, 50Hz/60Hz, 8A
Noise level [dB]	≤58
Acceleration /Braking time [Sec]	25s↑25s↓
Dimensions [mm]	(L)280×(D)364×(H)266
Weight	12kg
Additional Features	Speed/Acceleration switch; Short-time run function; sound-alert function

Optional accessories

Rotors: Aluminum alloy rotor kit with lid, fixing clips and O'ring

Model	Description	Available adapters	Picture
A18-5	Max. Speed (rpm) : 15000 Max. RCF (×g): 21380 Max. capacity: 5ml×18 Bio safe: Yes Use with: D3024; D3024R	NO
AS24-2	Max. Speed (rpm) : 15000 Max. RCF (×g): 21380 Max. capacity: 2ml×24 Bio sa fe: Yes Use with: D3024; D3024R	A02P2 A05P2
AS36-05	Max. Speed (rpm) : 15000 Max. RCF (×g): 21380 Max. capacity: 0.5ml×36 Bio safe: Yes Use with: D3024; D3024R	A02P05
AS4-PCR8	Max. Speed (rpm) : 15000 Max. RCF (×g): 21380 Max. capacity: 4×PCR8 Bio safe: Yes Use with: D3024; D3024R Available adapters: N/A	NO

Adapters:

A02P2	0.2ml rotor adapter, use with A12-2 & AS24-2 rotors,24pcs/pk
A05P2	0.5ml rotor adapter, use with A12-2 & AS24-2 rotors,24pcs/pk
A02P05	0.2ml rotor adapter, use with AS36-05 rotor,36pcs/pk
