SHB-IIIA Water Circulating Vacuum Pump

Flow: 80L/min
Capacity of water tank: 15L
Pressure: 0.098MPa (20mba), Low Pressure
Application: Water Distribution, laboratory, industry
Availability:
  • SHB-IIIA
  • NADE
  • 220V, 50Hz, or Optional 110V
  • 1
  • 1 year
  • China

Product Description

NADE SHB-IIIA Water Circulating Vacuum Pump for rotary evaporator

Introductions

Features and usages:

The series of Multi-purpose Circulating Water Vacuum Pump takes circulating water as working fluid, uses the negative pressure created by fluid jet to eject.

Providing vacuum condition for the processes of evaporation, distillation, crystallization, drying, sublimation, filtration and decompression, degassing and so on, particularly be suitable for labs and small scale test of industries such as universities and colleges, scientific research institutes, chemical industry, pharmacy, biochemistry, foodstuff, pesticide, agricultural engineering, biological engineering.

1. Cyclically use water, save the precious water resources.

2. Save more than 35% of electricity than other type of vacuum pump.

3. The fluid muffler purposemade can reduce the gas in water and make the vacuum degree higher and more stable; reduce the friction between gas and fluid, reduce the noise.

4. Double-tap, double-display, can be used alone or in parallel.

5. Resist corrosion by acid, alkali and solvents.

6. The special machine is made by the famous electric manufacture ODM with fluorine rubber sealing, the inner of which can’t be intruded by corrosive gas.

7. Can be used to extract corrosive gas, need to shorten the period of water changing.


Notice:

Need to replace the water in the flume regularly to ensure the purity of water quality, the vacuum degree and to avoid dirt stains.

Models:

  • SHB-Ⅲ: shell, flume, ejector, tee junction, check valve and gas-extraction nozzle adopt the PP material; pump body and impeller(six flow passages, dual seal) adopt stainless steel plate pressing, the material is in accordance with the ANSI standard.

  • SHB-ⅢA: ejector and gas-extraction nozzle adopt stainless steel material (ANSI standard), the rest is the same as SHB-Ⅲ.

  • SHB-ⅢS: pump body adopts the PP material, which is more suitable for acid gas, the rest is the same as SHB-Ⅲ.

  • SHB-ⅢT: lucid flume is convenient for observe water level and water quality, the rest is the same as SHB-ⅢA.

Specification:


Model

SHB-III series

Power(W)

180

Power supply(V/Hz)

220/50

Flow(L/min)

80

Lift(m)

10

Maximum Vacuum Degree(MPa)

0.098

Single Tap Air Sucking Amount(L/min)

10

Single Tap Air Sucking Amount(A)

2

Safety functions

Check valve

Capacity of water storage tank(L)

15

Materials of Water Tank

PP

Dimensions(mm)

385L×280W×420H

Weight(kg)

11

Suction nozzle (mm)

8


The configuration table(texture of material):

SHB-III

SHB-IIIA

SHB-IIIS

SHB-IIIG

Shell

PP

PP

PP

PP

The sink

PP

PP

PP

PP

Jet

PP

SUS304

PP

Copper+Teflon

Tee

PP

PP

PP

PP

Check valve

PP+Copper

SUS304

PP+Copper

PP+Copper

The suction nozzle

PP

SUS304

SUS304

Copper+Teflon

The pump body

SUS304

SUS304

SUS304

SUS304

Impeller

SUS304

SUS304

PA

SUS304

The connecting pipe

NR

NR

NR

FPM
