301Pt-S ORP Combination Electrode

ORP Range: ±2000mV
Temp Range: 0-80℃(32 to 176℉)
Connector: 8-pin
Housing: Polycarbonate
Availability:
  • 301Pt-S

  • NADE

  • 5

  • Yes

  • half a year

  • China

Product Description

We provide custom services, just contact us if you need it!!!301Pt Series

301Pt-S ORP Combination Electrode, 8pin Connector
301Pt-S ORP Combination Electrode is designed for use with the SX700 Series (SX711/SX731) and suitable for both lab and on-site measurements. Its high-quality platinum ring allows for easy cleaning and polishing, making it ideal for testing the bactericidal effect of conventional aqueous solutions (e.g., swimming pool water, mineral water, and drinking water) as well as analyzing redox systems in water treatment scenarios such as wastewater and electroplating solutions.


Application

PH910 APPLICATION

Specification

Item

301Pt-S ORP Combination Electrode

ORP Range

±2000mV

Temp range

0-80℃(32 to 176℉)

Connector

8-pin

Sensor

dia6*2.5mm platinum ring

Dimension

Dia12*160mm

Junction

Ceramic

Reference

Ag/AgCl

Housing

Polycarbonate
